WP-系列@支撑油缸- Collet-Lok®自锁设计
液压锁紧，机械式维持对工件的支撑
Collet-Lok®设计允许支撑油缸在去掉液压后维持支撑位置
Collet-Lok®自锁具有高水平的安全装置，并不依赖液压压力
所有支撑油缸中最小程度的变形
螺纹或法兰安装增加了安装的灵活性
| Max. Support Force | Support Plunger Stroke | Flange Models | Threaded Models | Operating Pressure |
Locking System Displacement |
Plunger Contact Spring Force | Max. Oil Flow | ||
|---|---|---|---|---|---|---|---|---|---|
| pound | inch | psi | in3 | pound | in3/min | ||||
| min. | max. | lock | unlock | ||||||
| 2000 | 0.39 | WPFS-100V | – | 1450 | 5000 | 0.24 | 0.24 | 4.50 | 400 |
| 4000 | 0.39 | WPFS-200V | – | 1450 | 5000 | 0.37 | 0.37 | 7.90 | 400 |
| 10,000 | 0.77 | WPFS-450V | – | 1450 | 5000 | 1.10 | 1.10 | 67.50 | 400 |
| 2000 | 0.39 | – | WPTS-100V | 1450 | 5000 | 0.24 | 0.24 | 3.37 | 400 |
| 4000 | 0.39 | – | WPTS-200V | 1450 | 5000 | 0.37 | 0.37 | 6.74 | 400 |
