NC-系列@液压螺母破切器
紧凑宜人的设计，使用方便
独特的角度头设计
单向作用弹簧回位液压缸
可重新研磨重型刀头
适合各种应用：卡车维修、管道工业、槽罐清理、石油化工、钢铁建筑、采矿等等
|
Bolt Range |
Hexagon Nut Range |
Capacity |
Oil Capacity |
Model Number |
Weight |
|---|---|---|---|---|---|
| in | in | ton | in3 | lbs | |
| .31-.50 | .50-.75 | 5 | 0.92 | NC-1319 | 1.8 |
| .50-.63 | .75-.94 | 10 | 1.22 | NC-1924 * | 4.4 |
| .63-.88 | .94-1.13 | 15 | 3.66 | NC-2432 * | 6.6 |
| .88-1.13 | 1.13-1.56 | 20 | 4.88 | NC-3241 * | 9.7 |
| 1.13-1.38 | 1.56-2.00 | 35 | 9.46 | NC-4150 | 18 |
| 1.38-1.50 | 2.00-2.25 | 50 | 14.64 | NC-5060 | 26 |
| 1.50-1.88 | 2.38-2.88 | 90 | 30 | NC-6075 | 75.1 |
* Available as Nut Splitter-Pump Sets
Max. allowable material hardness to split is HRc-44. Not to be used on square nuts.
