MS-系列@管子、连接件与适配器
19：管套
20：扩张器
21：锁销
22：锁接连接件
23：锁接公接头
24：锁接母接头
25：可调延伸轴杆
26：滑锁延伸轴杆
27：延伸管
注意: Only use attachments provided with set. Non-Enerpac attachments and longer extension tubes will reduce column strength
| Tubes, Connectors, Adaptors | Capacity & Model Number | Dimensions (inch) | |||||||
|---|---|---|---|---|---|---|---|---|---|
| 1,0 ton | 2,5 ton | 5,0 ton | 12,5 ton | A | C | D | |||
|
19 | – | A-544 | – | – | 3/4" -16 UN | – | 1.31 |
|
| 19 | – | – | A-19 | – | 1 1/4" - 11 1/2 NPT | – | 2.15 | ||
| 19 | – | – | – | A-242 | 2" - 11 1/2 NPT | – | 3.25 | ||
|
20 | WR-5 | – | – | – | – | .50 | 3.70 |
|
| 20 | A-92 | – | – | – | 2 1/4" - 14 UN | 1.38 | 6.25 | ||
| 20 | – | – | – | – | – | – | – | ||
|
21 | – | MZ-4013 | – | – | .25 | – | 2.38 |
|
| 21 | – | – | A-16 | – | .44 | – | 3.25 | ||
| 21 | – | – | – | – | – | – | – | ||
|
22 | – | MZ-4007 | – | – | .75 | – | 3.12 |
|
| 22 | – | – | MZ-1050 | – | 1.31 | – | 5.00 | ||
| 22 | – | – | – | – | – | – | – | ||
|
23 | – | MZ-4008 | – | – | 3/4" - 14 NPT | – | .75 |
|
| 23 | – | – | MZ-1051 | – | 1 1/4" - 11 1/2 NPT | – | 1.31 | ||
| 23 | – | – | – | – | – | – | – | ||
|
24 | – | MZ-4009 | – | – | 3/4" - 14 NPT | – | .75 |
|
| 24 | – | – | MZ-1052 | – | 1 1/4" - 11 1/2 NPT | – | 1.31 | ||
| 24 | – | – | – | – | – | – | – | ||
|
25 | – | – | – | – | – | – | – |
|
| 25 | – | – | A-285 | – | 1 1/4" - 11 1/2 NPT | 13.20-17.37 | 1.30 | ||
| 25 | – | – | – | – | – | – | – | ||
|
26 | – | A-650 | – | – | 3/4" - 14 NPT | 7.88-14.37 | – |
|
| 26 | – | – | – | – | – | – | – | ||
| 26 | – | – | – | – | – | – | – | ||
|
27 | – | MZ-4002 | – | – | 3/4" - 14 NPT | – | 3.0 |
|
| 27 | – | MZ-4003 | – | – | 3/4" - 14 NPT | – | 5.0 | ||
| 27 | – | MZ-4004 | – | – | 3/4" - 14 NPT | – | 10.0 | ||
| 27 | – | MZ-4005 | – | – | 3/4" - 14 NPT | – | 18.0 | ||
| 27 | – | MZ-4006 | – | – | 3/4" - 14 NPT | – | 23.0 | ||
| 27 | – | – | MZ-1002 | – | 1 1/4" - 11 1/2 NPT | – | 5.0 | ||
| 27 | – | – | MZ-1003 | – | 1 1/4" - 11 1/2 NPT | – | 10.0 | ||
| 27 | – | – | MZ-1004 | – | 1 1/4" - 11 1/2 NPT | – | 18.0 | ||
| 27 | – | – | MZ-1005 | – | 1 1/4" - 11 1/2 NPT | – | 30.0 | ||
| 27 | – | – | – | A-239 | 2" - 11 1/2 NPT | – | 10.0 | ||
| 27 | – | – | – | A-240 | 2" - 11 1/2 NPT | – | 18.0 | ||
| 27 | – | – | – | A-241 | 2" - 11 1/2 NPT | – | 30.0 | ||
