ZA4-系列@气动液压泵
秉承Z-系列泵效率高，流量大，旁边压力高的设计特点
双速操作减少循环周期，提高工作率
两个内置式溢流阀，一个是出场前设置好用于过载保护，另一个是用户可调溢流阀用于预设系统最大压力
所有尺寸的油箱都配有透明式液位计或液位指示器用于快速，方便的监控油箱液位
阀和油箱的多种配置形式可应用于一些特殊场合
高的旁通压力提高工作效率
选配的散热器可以加热废气防止冻结和降低油温
|
Used with Cylinder |
Usable Oil Capacity |
Valve Model Number 2) |
Valve Function |
Model Number |
Output Flow Rate 1) | Weight | |||
|---|---|---|---|---|---|---|---|---|---|
| (in3/min at psi) | |||||||||
| (gal) | 100 | 700 | 5000 | 10,000 | (lbs) | ||||
|
Single- acting |
1.0 |
Manual VM32 |
Advance/ Retract |
ZA4204MX | 850 | 675 | 110 | 80 | 65.5 |
| 1.75 | ZA4208MX | 850 | 675 | 110 | 80 | 75.7 | |||
| 5.0 | ZA4220MX | 850 | 675 | 110 | 80 | 112.7 | |||
|
Double- acting |
1.0 |
Manual VM43 |
Advance/ Hold/ Retract |
ZA4404MX | 850 | 675 | 110 | 80 | 66.7 |
| 1.75 | ZA4408MX | 850 | 675 | 110 | 80 | 76.9 | |||
| 2.5 | ZA4410MX | 850 | 675 | 110 | 80 | 87.1 | |||
| 5.0 | ZA4420MX | 850 | 675 | 110 | 80 | 113.9 | |||
| 10.0 | ZA4440MX | 850 | 675 | 110 | 80 | 164.6 | |||
1) Actual flow will vary with air supply
2) See valve section for hydraulic symbols and details
