P-系列@轻型手动泵
轻巧紧凑的设计
经久耐用强化工程塑料油箱和尼龙包封的铝制泵体耐腐蚀能力强
双速操作，手柄行程比单速操作时减少78%
手柄省力，降低操作者劳动强度
P-842泵配有4通阀可操作双作用油缸
可锁手柄和轻巧的结构便于携带
油箱容量大，可适用于较多型号的油缸和工具
特别手柄保证操作者安全
内置安全阀，用于过载保护
|
Pump Type |
Usable Oil Capacity |
Model Number |
Pressure Rating* |
Oil Displacement per Stroke |
Max. Handle Effort |
Piston Stroke |
Weight | ||
|---|---|---|---|---|---|---|---|---|---|
| psi | in3 | ||||||||
| in3 | 1st stage | 2nd stage | 1st stage | 2nd stage | lbs | in | lbs | ||
| Single-speed | 20 | P-141 | - | 10,000 | - | .055 | 72 | .50 | 4.5 |
| 55 | P-391 | - | 10,000 | - | .151 | 85 | 1.00 | 9.0 | |
| Two-speed | 20 | P-142** | 200 | 10,000 | .221 | .055 | 78 | .50 | 5.3 |
| 55 | P-202 | 200 | 10,000 | .221 | .055 | 63 | .50 | 7.5 | |
| 55 | P-392** | 200 | 10,000 | .687 | .151 | 93 | 1.00 | 9.0 | |
| 155 | P-802 | 400 | 10,000 | 2.40 | .151 | 95 | 1.00 | 18.0 | |
| 155 | P-842*** | 400 | 10,000 | 2.40 | .151 | 95 | 1.00 | 22.0 | |
* Contact Enerpac where operating pressure is less than 10% of pressure rating.
** Available as set.
*** For use with double-acting cylinders.
