CA, MA-系列@夹紧臂 用于摆动油缸
专利设计
在任意位置夹紧臂均可方便精确地定位
油缸安装在夹具面上后夹紧臂也可方便而精确地安装与固定
无需用夹钳紧固夹紧臂
压力与夹紧力的曲线图
选用不同长度的夹紧臂要求相应的油压会导致不同的夹紧力
压力 vs. clamping force
The use of different 长度 clamp arms requires reduction in applied hydraulic 压力 and resulting clamp force. Download the catalogue page showing the diagrams showing the 压力 versus clamping force
|
Clamp Arm Length |
Clamping Force |
For Swing Cylinders |
For Collet-Lok® |
Clamp Arm Model Number |
|
|---|---|---|---|---|---|
|
SU, SL-Series ST, SC Series |
WPFL/R-series WPTL/R-series |
||||
| inch | pound |
Standard Arm |
Long Arm |
||
| 1.60 | 500 | 21, 22 | – | CAS-21 | – |
| 2.39 | 1250 | 51, 52 | – | CAS-51 | – |
| 2.99 | 2025 | 92 | – | CAS-92 | – |
| 3.13 | 2600 | 121, 122 | – | CAS-121 | – |
| 3.72 | 4200 | 201 | – | CAS-201 | – |
| 4.65 | 7600 | 351 | – | CAS-351 | – |
| 3.63 | 500 | 21, 22 | – | – | CAL-22 |
| 5.81 | 1250 | 51, 52 | – | – | CAL-52 |
| 7.09 | 2025 | 92 | – | – | CAL-92 |
| 7.06 | 2600 | 121, 122 | – | – | CAL-122 |
| 7.95 | 4200 | 201 | – | – | CAL-202 |
| 8.47 | 7600 | 351 | – | – | CAL-352 |
