BRC, BRP-系列@单作用拉式液压油缸
高强度合金钢结构
柱塞限位结构，防止活塞过渡深处
镀铬柱塞使寿命更长
烤漆表面使耐腐蚀能力更强
所有型号均包含CR-400快速接头及防尘帽
防尘圈减少污染，延长液压缸使用寿命
单作用，弹簧回缩
BPR-系列可替换连接件
|
Cylinder Capacity |
Stroke | Model Number |
Cylinder Effective Area |
Oil Capacity |
Collapsed Height |
Extended Height |
Outside Diameter |
Weight |
|---|---|---|---|---|---|---|---|---|
| ton (max) | (in) | (in2) | (in3) | (in) | (in) | (in) | (lbs) | |
| 2.5 (2.7) | 5.00 | BRC-25 | .55 | 2.76 | 10.44 | 15.44 | 1.89 | 4 |
| 5 (5.6) | 5.50 | BRC-46 | 1.13 | 6.21 | 11.88 | 17.38 | 2.25 | 10 |
| 10 (11.6) | 5.95 | BRC-106 | 2.32 | 13.80 | 11.38 | 17.33 | 3.35 | 21 |
| 10 (11.6) | 6.00 | BRP-106C* | 2.32 | 13.80 | 23.11 | 29.06 | 3.35 | 35 |
| 10 (11.6) | 6.00 | BRP-106L* | 2.32 | 13.80 | 22.24 | 28.19 | 3.35 | 24 |
| 30 (36.1) | 6.00 | BRP-306* | 7.22 | 43.27 | 42.72 | 48.82 | 5.39 | 106 |
| 60 (58.8) | 6.00 | BRP-606* | 11.78 | 70.43 | 28.34 | 34.32 | 5.51 | 118 |
Note: BRP-106C, BRP-106L and BRP-606 are fitted with rubber bellows for rod protection.
*Also available as cylinder-pump sets.
