MS-系列@基座，外环端脚，柱塞附件
1：螺纹配件
2：基座附件
3：提升端脚
4：平底座
5：螺纹连接件
6：可锁接的夹钳支脚
7：旋接在柱塞上的支脚
8：外环夹钳头
9：扩张支脚
10：锯齿鞍座
11：平鞍座
12：90度V座
13：柱塞座
14：楔头
15：橡胶顶头
注意： 不使用附加件时的工作能力为此数据的两倍,最大工作压力为700bar
| Base / Collar / Plunger Attachments | Capacity & Model Number |
Dimensions (inch) |
|||||
|---|---|---|---|---|---|---|---|
| 2,5 ton | 5,0 ton | 12,5 ton | A | D | |||
|
1 | A-23 | – | – | 3/4" -16 UN | 3/4" -14 NPT |
|
| 1 | – | A-13 | – | 1" - 8 UN | 1 1/4" - 11 1/2 NPT | ||
| 1 | – | – | A-28 | 1 1/2" -16 UN | 2" - 11 1/2 NPT | ||
|
2 | A-25 | – | – | 3/4" -14 NPT | 1.75 |
|
| 2 | – | A-21 | – | 1 1/4" - 11 1/2 NPT | 2.56 | ||
| 2 | – | – | A-27 | 2" - 11 1/2 NPT | 3.86 | ||
|
3 | A-1034 | – | – | 1 1/2" - 16 UN | 1.25 |
|
| 3 | – | A-20 | – | 2 1/4" - 14 UN | 2.25 | ||
| 3 | – | – | A-595 | 3 5/16" 12UN | 3.18 | ||
|
4 | A-4010 | – | – | 3/4" - 14 NPT | 2.50 |
|
| 4 | – | A-14 | – | 1 1/4" - 11 1/2 NPT | 3.50 | ||
| 4 | – | – | A-243 | 2" - 11 1/2 NPT | 6.50 | ||
|
5 | A-545 | – | – | 3/4" - 14 NPT | – |
|
| 5 | – | A-10 | – | 1 1/4" - 11 1/2 NPT | – | ||
| 5 | – | – | – | ||||
|
6 | – | – | – | – | – |
|
| 6 | – | A-8 | – | 1.69 | 2.25 | ||
| 6 | – | – | – | – | – | ||
|
7 | A-530 | – | – | 3/4" - 14 NPT | 1.33 |
|
| 7 | – | A-6 | – | 1 1/4" - 11 1/2 NPT | 2.25 | ||
| 7 | – | – | – | – | – | ||
|
8 | MZ-4011 | – | – | 3/4" - 14 NPT | 1 1/2" - 16 UN |
|
| 8 | – | A-192 | – | 1.69 | 2 1/4" - 14 UN | ||
| 8 | – | – | – | – | – | ||
|
9 | – | – | – | – | – |
|
| 9 | – | A-305 | – | 1 1/4" - 11 1/2 NPT | 2.00 | ||
| 9 | – | – | – | – | – | ||
|
10 | A-531 | – | – | 3/4" - 14 NPT | – |
|
| 10 | – | A-18 | – | 1 1/4" - 11 1/2 NPT | – | ||
| 10 | – | – | – | – | – | ||
|
11 | – | – | – | – | – |
|
| 11 | – | A-185 | – | 1 1/4" - 11 1/2 NPT | 2.00 | ||
| 11 | – | – | – | – | – | ||
|
12 | A-532 | – | – | 3/4" - 14 NPT | 1.00 |
|
| 12 | – | A-15 | – | 1 1/4" - 11 1/2 NPT | 2.13 | ||
| 12 | – | – | – | – | – | ||
|
13 | – | – | – | – | – |
|
| 13 | – | – | – | – | – | ||
| 13 | – | – | A-607 | 2" - 11 1/2 NPT | 6.56 | ||
|
14 | A-629 | – | – | 3/4" - 14 NPT | 1.13 |
|
| 14 | – | A-129 | – | 1 1/4" - 11 1/2 NPT | 1.75 | ||
| 14 | – | – | – | – | – | ||
|
15 | A-539 | – | – | 3/4" - 14 NPT | 2.75 |
|
| 15 | – | A-128 | – | 1 1/4" - 11 1/2 NPT | 3.14 | ||
| 15 | – | – | – | – | – | ||
