PGM-2304R@Atlas汽油泵
专利创新技术：
- 同轴柱塞设计保证高性能
- 第一级柱塞提高泵效率
|
Used with Cylinder |
Usable Oil Capacity (gal) |
Model Number |
Output Flow Rate** (in3min) |
Pressure Rating (psi) |
Valve Type | Valve Function | Motor Manufacturer |
Motor Size (Ft.lbs) |
Weight (lbs) |
|
|---|---|---|---|---|---|---|---|---|---|---|
|
1st stage |
2nd stage |
|||||||||
|
Single-acting |
1.0 | PGM-2304R* | 200 | 40 | 10,000 | 3-way, 3-position |
Advance/ Hold/Retract |
Honda |
4.2 at 3600 rpm |
55 |
| 2.0 | PGM-2308R* | 200 | 40 | 10,000 | 3-way, 3-position | 72 | ||||
|
Double-acting |
1.0 | PGM-2404R* | 200 | 40 | 10,000 | 4-way, 3-position | 55 | |||
| 2.0 | PGM-2408R* | 200 | 40 | 10,000 | 4-way, 3-position | 72 | ||||
* Note: The PGM-20 series are also available with a carrying handle instead of a rollcage:
for ordering omit the "R" from the model number.
** Nominal values-may vary based on motor speed.
