PL-系列@拉力油缸-下法兰式
最小安装高度，当空间有限
导向式直线活塞杆运动
柔性设计可选用油路块或螺纹接口连接 ace
低轮廓安装类型允许缸体在安装表面以下
活塞杆的内螺纹更易安装附件
简单的在线安装设备
易于加工的夹具安装孔，公差要求低
只有3到4个螺栓就可简单装配
两种油口选择：螺纹连接或油路块安装
|
Cylinder Capacity |
Stroke |
Model Number |
Cylinder Effective Area |
Oil Capacity |
|||||
|---|---|---|---|---|---|---|---|---|---|
| pound | inch | S/A | D/A | inch2 | inch3 | ||||
| pull | push | pull | push | pull | push | ||||
| 1250 | – | 0.89 | PLSS-51 | • | – | 0.28 | – | 0.25 | – |
| 2950 | – | 1.10 | PLSS-121 | • | – | 0.63 | – | 0.70 | – |
| 1400 | 2950 | 0.89 | PLSD-51 | – | • | 0.28 | 0.59 | 0.25 | 0.53 |
| 2475 | 6300 | 0.86 | PLSD-92 | – | • | 0.49 | 1.25 | 0.42 | 1.08 |
| 3150 | 6150 | 1.10 | PLSD-121 | – | • | 0.63 | 1.23 | 0.70 | 1.40 |
| 9600 | 18,400 | 1.20 | PLSD-351 | – | • | 1.92 | 3.68 | 2.27 | 4.35 |
Note: Pull forces for single-acting cylinders reduced to overcome spring force.
