CAU-系列@鹤形夹紧臂
Enerpac upreach clamp arms for swing cylinders by design allow for more flexible part clamping
Arm can be easily installed and fastened while the cylinder is mounted in the fixture to allow exact arm positioning
Patented design – vise not required for fastening arms
Clamp arm 长度 can be cut to desired size
Angled arm with minimal deflection achieves maximum workpiece contact
|
Maximum Clamp Force * |
Upreach Clamp Arm Model Number |
Minimum Arm Length |
Standard Arm Length |
Clamp Arm Fits on Swing Cylinder Series/Models |
|||
|---|---|---|---|---|---|---|---|
| lbs | inch | inch | SU- | SL- | ST- | SC- | |
| 100 - 500 | CAU-22 | 0,98 | 3,25 | 21 | 21 | 21 | 22 |
| 200 -1250 | CAU-52 | 1,57 | 5,31 | 51 | 51 | 51 | 52 |
| 450 - 2025 | CAU-92 | 1,77 | 6,3 | 92 | 92 | 92 | – |
| 500 - 2600 | CAU-122 | 2.00 | 6,36 | 121 | 121 | 121 | 122 |
| 1000 - 4200 | CAU-202 | 2,17 | 6,99 | 201 | 201 | 201 | – |
| 1900 - 7600 | CAU-352 | 2,68 | 7,09 | 351 | 351 | 351 | – |
* Maximum clamp force at clamp arm length from minimum (customized) to standard (stock) length.
